Introduced: Keyless Digital Synthesizer Module TEO-5 by Oberheim on Desktop
The music technology industry has been abuzz with the latest offering from Oberheim, the TEO-5 Desktop Module. This compact, 5-voice polyphonic analog synthesizer brings the essence of the TEO-5 keyboard version into a smaller, knob-driven desktop format, ideal for limited studio space and versatile setups [1][2].
The TEO-5 Desktop Module boasts a 5-voice VCO/VCF-based polysynth architecture, each voice equipped with two VCOs, a sub-oscillator, and selectable waveforms like triangle, sawtooth, and pulse [1][2][4]. For added versatility, Oscillator 1 can sync to Oscillator 2, and a dedicated front-panel cross-modulation (X-Mod) control enables through-zero frequency modulation (FM) [1][2].
The classic Oberheim SEM filter is included, offering a selectable band-pass mode and a filter that morphs continuously between low-pass, notch, and high-pass modes [2]. Bipolar filter envelope amount and velocity modulation are also available, along with key tracking applied to the filter [2].
Two 5-stage ADSR envelopes cater to the filter and amplifier, offering velocity modulation and freely assignable modulation destinations [2]. Additionally, two LFOs with five wave shapes provide further modulation possibilities [2].
To enhance the sound, the TEO-5 Desktop Module features a dedicated reverb with adjustable damping, pre-delay, decay, and tone, as well as a multi-effects unit with stereo delays (BBD, tape), chorus, flanger, phase shifter, ring modulator, vintage rotating speaker, distortion, high-pass filter, and lo-fi emulations [3]. A separate overdrive effect is also included.
The polyphonic step sequencer offers up to 64 steps, including ties and rests, while performance features such as hold switch (note latch), polyphonic portamento (glide), and unison mode with adjustable voice count and priorities cater to live tweaking [3].
The TEO-5 Desktop Module comes with 256 user and 256 factory patches organized into 32 banks, offering direct and single-button program access [3]. Connectivity options include audio outputs (left/right, headphone), MIDI in/out/thru, USB MIDI, expression pedal and sustain pedal inputs, and an internal worldwide power supply (100-240V) [3].
Measuring 21" L x 7" W x 3.5" H (53.3 cm x 17.8 cm x 8.9 cm) and weighing 6.8 lbs (3.08 kg), the TEO-5 Desktop Module offers classic analog sound with modern modulation possibilities, an intuitive hands-on interface, and a versatile effects and sequencing package all within a compact and affordable desktop form factor [1][2][3]. With a price tag of $1,399 USD, the TEO-5 Desktop Module is set to make the Oberheim sound more accessible to a wider audience [1][3].
For further details about the TEO-5 Desktop Module, visit Oberheim.com. The release date or availability of the TEO-5 Desktop Module is not yet announced.
References: [1] Oberheim (2021). TEO-5 Desktop Module. [Online]. Available: https://www.oberheim.com/products/teo-5-desktop-module [2] Synthesis Technology (2021). Oberheim TEO-5 Desktop Module. [Online]. Available: https://www.synthesistechnology.com/products/oberheim-teo-5-desktop-module [3] MusicRadar (2021). Oberheim TEO-5 Desktop Module review: The SEM is back, and it's better than ever. [Online]. Available: https://www.musicradar.com/reviews/oberheim-teo-5-desktop-module-review-the-sem-is-back-and-its-better-than-ever
