Self-Made Linear Tube Motor Performs Accurate Gliding Movements

Flaunting Some DIY Linear Motor Magic!

Oh boy, check out this DIY Tubular Linear Motor that'll knock your socks off! Pulled together by none other than [Jeremy], it's a head-turning twist on the conventional stepper motor. Built as a fun design experiment for a DIY gearless actuator, it definitely deserves a gander.

So, what makes it tick? The core is a round chamber stuffed with magnets, gliding back and forth through a line of energized coils, creating a quiet, gearless linear actuator that moves like a charm. It's like you unrolled a rotary stepper motor and, voilà, there you have it!

Jeremy dived right in, delving deep into experimentation on coil design and fine-tuning magnet spacing and orientation, without letting a lack of expertise in motor design or assembly hold him back. We're all about that exploratory spirit!

Now, you might have encountered DIY linear motors nestled within PCBs or even commandeering model train tracks, but this marks the first time we've seen one rocking the tubular style.

Curious to see it in action? The zesty video below has got you covered! Dig a little deeper into the mind-blowing Project Log for more nitty-gritty details!

By the way, if you want to replicate this DIY tubular linear motor, there are a few critical elements to keep in mind: selecting or designing the moving magnets and stationary coils, understanding magnet and coil orientation, and efficiently arranging components for minimal friction and max performance.

Here's a lowdown on the essential components and principles:

Tubular Structure: Your DIY motor will likely be composed of a non-magnetic tube (acrylic, aluminum, or PVC) as the main frame, with coils wound on the inside, and magnets stacked inside the tube.
Magnet Stack: Strong magnets (neodymium, ring or cylindrical) will be alternated in polarity (N-S-N-S) and glued together with space condiments (non-magnetic washers) to control the spacing and prevent snapping.
Coil Assembly: Coils, strategically positioned and oriented, will create a magnetic field when energized, propelling the magnet stack linearly. A single or multiple coils could be deployed depending on the design.

If you're ready to rock and roll, follow these baby steps to get your tubular motor thumpin' and a-hummin':

1. Choose the Tube and Magnets- Tube: Opt for a non-ferromagnetic material to sidestep magnetic interference. The diameter should allow the magnet stack to slide around sans hassle.- Magnets: Select cylindrical NdFeB magnets that are all the same size and strength. Nail the number and spacing for optimal performance.

2. Magnet Stack Construction- Polarity Orientation: Magnetize the stack by stacking alternatively (N-S-N-S), using spacers (non-magnetic washers) to glue them together and regulate the spacing.- Magnet Spacing: Properly space the magnets to match the coil geometry. For most builds, magnet spacing is equivalent to the coil’s axial length or its fraction (such as half or a quarter of the coil pitch).

3. Coil Design and Windings- Coil Dimensions: Lengthwise, the coil should be equal to or just slightly smaller than the spacing between like poles (but it depends on experimentation). Coils are wound on a mandrel fitting the tube’s inner diameter.- Number of Turns: More turns expand the magnetic field but increase resistance. Choose an optimal wire gauge to strike a balance between current/voltage and heat.- Coil Orientation: Place coils so their magnetic field interacts efficiently with passing magnets. Coils are usually aligned sequentially along the tube.

4. Assembly- Coil Mounting: Fix the coils securely inside or around the tube, making sure they don't obstruct the magnet stack’s motion.- Guide Rails: Use friction-reducing bushings or bearings to guide the magnet stack, minimizing friction and averting binding.- Electrical Connections: Connect coils to a controller (such as an H-bridge or ESC) for direction and speed manipulation.

5. Optimal Design Considerations- Magnet Spacing and Coil Pitch: To achieve smooth thrust, the coil pitch (distance between coil centers) should match the distance between equivalent magnet points. For a stack with alternating N-S magnets, this is usually double the magnet thickness plus the spacer.- Magnetic Circuit: Make sure the magnetic flux's return path doesn't choke. In a tubular motor, this is often managed by the air/plastic/aluminum of the tube and not through a ferromagnetic core.- Phase Timing: For multi-phase operation, activate coils sequentially as passing magnets are detected, using sensors or sensorless commutation.

And there you have it! Now, go create some magic with your DIY tubular linear motor!

Trust us, devilishly fun details await you in this sexy project log.

This DIY tubular linear motor is not just another gadget in the realm of technology, but it's a unique creation that showcases Jeremy's passion for DIY projects and expertise in motor design. You might have seen linear motors in PCBs or model train tracks, but this DIY project is an innovative take on the tubular style, efficiently using coils and magnets to create a quiet, gearless linear actuator. To replicate this DIY motor, consider the essential components such as a tubular structure, a magnet stack, and coil assembly, and remember that experimentation is key to achieving optimal performance.
