Simplified Guidance for Novice Aviators: Navigating RNAV Approaches
Ready to soar with RNAV approach? Here's a breakdown!
RNAV (Area Navigation) steers you to your destination without radio beacons, relying on modern GPS instead. Compared to old-school radios, it's more reliable and flexible, working brilliantly over water or around any issues that interfere with regular radio waves.
RNAV helps you fly a more direct path to your destination, easing the need for zigzagging between ground-based navigation aids.
Key Points:
- Compared to VORs and NDBs, RNAV uses GPS waypoints for direct routes.
- Various types of RNAV approaches include LPV, LNAV, LP, LP+V, LNAV/VNAV, and RNP.
- Precision systems like LPV allow for lower minima, ensuring safer landings in poor visibility.
- Thanks to RNAV, beacons are only backup options, providing better access and efficiency.
What's RNAV?
Put simply, RNAV is a way for pilots to navigate without the need for ground-based signals. It leverages GPS technology for trusted guidance.
Before RNAV, pilots heavily relied on VORs (Very High-Frequency Omnidirectional Range) and NDBs (Non-Directional Beacons). These beacons directed the pilots when they couldn't see anything outside their airplane.
However, VORs and NDBs Experience issues, like not being able to work over water or if something blocked radio waves.
So, enter RNAV – the better alternative, helping pilots navigate safely!
How RNAV Works?
Instead of relying on physical beacons, RNAV uses GPS for guidance, with waypoints taking the lead. Waypoints are simply named coordinates based on latitude and longitude. They don't have a physical presence, eliminating issues related to the location of ground-based beacons.
RNAV's global satellite coverage allows for setting waypoints anywhere – even over the ocean!
Approximately 4000 LPV approaches and 2000 airports currently support RNAV in the US.
Types of RNAV GPS Approaches:
Now, let's dive into the different types of RNAV approaches:
Type of Guidance:
Instrument approaches provide two types of navigational guidance:
- Lateral guidance helps you align yourself with the runway.
- Vertical guidance informs you if you are too high or too low on the approach path.
All instrument approaches provide lateral guidance, while some include vertical guidance as well.
With Vertical Guidance:
- Localizer Performance with Vertical Guidance (LPV) – LPV mimics ILS, providing both lateral and vertical guidance.
- Lateral Navigation/Vertical Navigation (LNAV/VNAV) – Offers horizontal and vertical guidance. Pilots may encounter restrictions with baro-VNAV.
Without Vertical Guidance:
- Lateral Navigation (LNAV) – Provides lateral guidance using GPS.
- Lateral Navigation/Lateral Guidance (LP) – Offers lateral guidance through enhanced GPS.
Both LP and LNAV share charts if LP offers lower minima. pilots will need RAIM checks for LNAV without GPS enhancements.
Approach Minimums:
When you're flying in poor visibility, it's necessary to rely on instruments until you reach a certain point. At this point, known as the Decision Height (DH), you make the call: land or go around.
The image provided is an example of an RNAV approach plate for Monterey Regional, California. The minima table illustrates the Decision Height (DH) and Height Above Threshold for each type of RNAV approach.
Localizer Performance with Vertical Guidance (LPV):
LPV stands for Localizer Performance with Vertical Guidance. It provides both lateral and vertical guidance for pilots. LPV is precise, resembling ILS requirements and may go as low as 200 feet above ground level (AGL).
LPV works by utilizing WAAS – a satellite-based system – to give accurate GPS information.
To fly an LPV approach, ensure your aircraft has a WAAS-capable GPS receiver.
Lateral Navigation (LNAV):
LNAV offers only lateral navigation and does not include vertical guidance. However, it communicates step-by-step altitude restrictions (fixes) throughout the approach. LNAV requires only an IFR-certified GPS.
Minimum Descent Altitude (MDA) applies instead of a Decision Altitude (DA) without vertical guidance. When you reach the MDA, pause before reaching the missed approach point (MAP), and – if you can't see the runway or markers – execute the missed approach procedure.
Localizer Performance (LP):
LP stands for Localizer Performance and is more accurate than LNAV because it uses WAAS technology. However, it only gives you lateral guidance.
RNP Approach:
RNP (Required Navigation Performance) measures the accuracy of RNAV approaches. In short, RNP ensures your navigation system continuously checks how accurately it's navigating.
If you fly RNP 1, your aircraft must stay within 1 nautical mile of the intended flight path 95% of the time. If your aircraft deviates from the flight path, it alerts the pilot to correct course.
This precision allows pilots to navigate in complex situations, like around mountains or other obstacles, where older systems would fail.
Most RNP approaches (RNP APCH) begin with RNP 1 accuracy and tighten up as you get closer to the runway, going down to RNP 0.3.
Some RNP approaches require stricter accuracy. These are called RNP Authorization Required which requires both aircraft and pilot certification, as well as special equipment.
